Turkey Broiler Feed Pellet Production Line With Siemens Motor
Advantages of Turkey Broiler Feed Pellet Production Line main machine
Tear-circle hammer mill crusher machine
Impeller feeder, feed evenly, prevent blocking
Cylinder automatic dust removal
Tungsten carbide hammer
China famous meishan sieve
Hammer sieve distance 0.8-1mm
Serpentine Spring Coupling, Protecting Motor
Double shaft paddle mixer machine
1. Hardened gear reducer
2. SKF bearing and Bearing seat
3. Two injection oil systems
4. Paddle: Laser cutting machine processing, 3mm distance with mixed wall
5. Bottom cylinder type discharge
Ring die feed pellet machine
US CPM models, use of high-strength precision gear transmission, transmission efficiency up to 99%, The normal belt type transmission efficiency of 90% -95%, And the belt type easy to loose and slippery, service life is short, when the belt becomes loose, the transmission efficiency will drop a lot. Under normal circumstances the same model with the power of the gear particles than the belt drive particle machine output is higher 20% -30%.
Host bearings adopt the top ten brands in the world, SKF (Switzerland) bearings, reliable quality, long service life! Particle machine tail has a protective switch device installed, when the spindle bearing and spindle lock, the timely cut off the power, the spindle and has an effective protective effect !
Crumbler machine
Three-roller structure, balanced and continuous work, advantages of equal sizes of finished products, high broken efficiency.
Less grading returned materials, high rate of finished products, Installed with feeder, low consumption
Counter-flow cooler machine
Eight corner structure without residue
High temperature resistance of Inspection window
Direct type reducer, Motor with emergency stop
Screener machine
Simple and convenient structure of sieve, quick replacement of sieve.
Simple-layer sieve, two-layer sieve, three-layer sieve are available
Widely used in grading and sieving of pellets and crushed materials, secondary cycle crush process, cleaning and grading of some pellets and powder.
Technical Parameters of Turkey Broiler Feed Pellet Production Line
| 10 T/H Poultry Automatic Feed Pellet Production Line |
| No. | Product name | Model | Power(kw) |
| 1. material receiving section |
| 102 | pulse dust collector | TBLFa.18 | |
| 105 | granule material clean sieve | SCY80 | 0.75 |
| 106 | permanent magnetic | TXCT25 | |
| 108 | powder cleaner | SCQZ80 | 11 |
| 109 | permanent magnetic | TXCT25 | |
| 2. material grinding section |
| 206 | Impeller feeder | SYLW3 | 1.5 |
| 207 | series tear-circle hammer mill | SDH-ZW50C | 132 |
| 210 | seal screw conveyor | SWLL25 | 6 |
| 3. batching and mixing section |
| 313 | double shaft high efficient mixer | SSHJ.2 | 18.5 |
| 314 | scrapper conveyor | TGSU25 | 3 |
| 315 | Bucket elevator | TDTG48.28 | 5.5 |
| 316 | powder material clean sieve | SCQZ75×65×1 40 | 7.5 |
| 317 | permanent magnetic drum | TXCT30 | |
| 4. pelleting section |
| 408 | Pellet machine | SZLH420 | 110 |
| 410 | counter-current cooler | SKLN6 | 1.5 |
| 410-1 | crusher | SSLG20×170 | 15 |
| 415 | classic sieve | SFJH125 | 3 |
| 5. packing section |
| 501 | Finished product bin | | |
| 506 | automatic packing scale | SDBY-P | |
| 507 | seal conveyor machine | TFKB40 | 3 |
| 509 | pulse dust collector | TBLFa.24 | |
| 510 | seal machinery | | 0.75 |
| 6.auxiliary system |
| 601 | Air compressor | | 22 |
| 603 | liquid adding machine | SYTV32 | 3 |
| 604 | liquid adding pipeline | | |
| 606 | boiler system | | |
